2.0.5 High Availability (HA)

Abbreviations, used in manual:

EF - Execution Flow

How to add additional servers to be slave nodes

Quilliup supports a scale-up architecture by adding multiple Tomcat engine servers (multi-instance setup) that share the same metadata repository. These additional servers act as slave nodes, monitoring the execution queue and helping process tests once the queue is loaded.

Note: Slave nodes are supported for run_qp.exe commands (Windows) only.

Configuration File

Path:

..\quilliup\webapps\ROOT\utils\run_qp.config1

or

..\quilliup\webapps\ROOT\utils\run_qp.exe.config1

To enable High Availability (HA):

• Rename the configuration file to: run_qp.exe.config

• Ensure that run_qp.exe.config is located in the same directory as run_qp.exe, especially when executing commands from a remote server.

Configuration Parameters

• available_servers – List of server URLs, separated by commas.

• timeout_retries – Number of retries if a ping/remote call fails due to timeout (independent of alternate_each_server).

• alternate_each_server – Defines how often Quilliup switches between servers while all servers are available:

  • 1 → switch servers every command

  • 2 → switch servers every two commands

  • etc.

  • From version 2.7.2, this parameter can include multiple values (comma-separated), matching the number of servers in available_servers.

• ping_timeout – Number of seconds to wait for a response when verifying if a server is available.

• current_index – Index of the server currently in use, relative to the available_servers list.

• current_index_use – Number of consecutive times the current server was used.

⚠️ The application must have read/write permissions for this folder to allow creation and modification of these files.



Example – run_qp.exe.config (the file should be defined in one/main instance only, no need to configure it within other instances):

<?xml version="1.0"?>
<configuration>
<startup>
<supportedRuntime version="v4.0"/>
</startup>
<appSettings>

 <add key="available_servers" value="http://192.168.50.138:8080,http://192.168.50.92:8080" />
<add key="timeout_retries" value="2" />
<add key="alternate_each_server" value="5,3" />
<add key="ping_timeout" value="3" />
<add key="current_index_use" value="0" />
<add key="current_index" value="0" />

</appSettings>
</configuration>

• Command Execution Example:

run_qp.exe -u  "http://192.168.50.138:8080" -a "YWRtaW5AUURtaW4=" -f "2974645" –d

• http://192.168.50.138:8080 → main instance

• -f "2974645" → EF containing 5 Tests

Execution behavior:

• Quilliup first attempts the primary instance (192.168.50.138).

• If it does not respond within 30 seconds, Quilliup automatically tries the next server (192.168.50.92).

• This process continues until an available server is found.

• Load Distribution Example :

With the following configuration: <alternate_each_server> = 5,3

• The first 5 commands run on SERVER1 (192.168.50.138)

• The next 3 commands run on SERVER2 (192.168.50.92)

• Rotation continues in this pattern.

Important: Each run_qp command is treated as one process, regardless of whether it executes an EF (with multiple tests) or a single test.
